نام محصول:
دریچه کره
نام انگلیسی:
Globe valve
برند:
pneumaticairactuator.com
مشخصات:
Globe straight-way series is a very versatile control valve for the main applications. Its high performance derives from using a balanced and cage-guided plug. ET series is particularly suitable for heavy duties and for any other application under the most demanding service conditions. Due to their simple construction, large range of trim types, and available materials, these valves are suitable for a wide range of applications, including also high temperature and corrosive fluids, severe low-noise requirements, and sour service in accordance with NACE standards.
Main advantages:
High-pressure drop capability with no practical limitations
Improved plug stability due to large guiding areas
Wide-range capability is allowed by a great number of reduced capacity trims
Excellent noise attenuation with low-noise single-stage trim for gas and steam service
Improved cavitation protection on liquid services
Multistage trims are also available for cavitation control.
Balanced plug construction reduces thrust and actuator sizes
Piloted plug construction for tight shut-off up to class V in high-temperature services
Technical characteristics:
Connection: Flanged, butt-welded, socket-welded, and threaded
Leakage Standard: ANSI/FC, IEC60534-4
Flow direction: flow to open, flow to close
Materials: A216 Cr. WCB, SS304, SS316, CF8M, CF3M, CF3, CF8, LCB, LCC, 2205, Duplex stainless steel etc.
توضیحات:
Type
globe
Operation
pneumatic
Function
for control, shut-off
Media
for gas
Body$
flange, threaded, welded, straight
Applications
for liquids
Material$
stainless steel
Fluid specification
for corrosive fluids
Other characteristics
standard, ANSI, high-pressure, high-performance, high-temperature, heavy-duty, low-noise
DN
Min.: 0.5 inMax.: 8 in
