نام محصول:
دریچه چک توپ
نام انگلیسی:
Ball check valve LCV34
برند:
FCTechnik – Gas Control Systems – flox[on] MFC
مشخصات:
Ladle treatment with stirring gas by purging plugs is an essential issue within secondary metallurgy. Reliable performance of the stirring plugs in steelmaking ladles is a key factor for accurate steel production.
Disturbances due to loss of stirring efficiency and non-stirring events have impact on treatment times and achievement of steel quality requirements.
To prevent infiltration at the ladle purging plug a check valve could be installed in the supply piping. The check valve maintains the immediate pressure at the plug in case the supply line discharges.
The check valve type LCV34 is in a stainless steel housing with a spring suitable for higher temperatures. Due to the spring forced closing of the valve it functions in any mounting orientation
Also available is a test unit for purging plugs.
The test unit TST is designed to test the purging plugs in the ladle preparation area. This is to avoid purging failures in the following heat and to prevent the purging plug from unnecessary excessive cleaning (burning, torching) with oxygen.
Test Unit TST for Purging Plugs
توضیحات:
Type
ball
Fluid
for gas
Applications
high-temperature
Material
stainless steel, brass
Other characteristics
spring, high-temperature
DN
13 mm(0.512 in)
Pressure
40 bar(580.2 psi)
Temperature
450 °C(842 °F)
