نام محصول:
دریچه لغزنده
نام انگلیسی:
Slide valve Ares
برند:
OMAL Spa
مشخصات:
Valve ends: see code plan.
Assembling is possible in all positions: upright, flat or angled.
Range available from DN 15 to DN 50 in the Double Acting versions, Spring
Return N.C. from above and below the plug, Spring Return N.O. from below the plug.
The performance and the pressure’s diagrams are the same as per Standard versions but limited at PN16
On request: versions for vacuum and oxygen service 2014/34/EU ATEX configuration to request at time of order.
CONTROL MEDIA:
Driving media: compressed air, lubricated or dry, gas or neutral media.
OPERATING MEDIA:
Air, water, alcohol, oil, petroleum products, saline solutions, steam, etc. (as long as compatible with CF3M (316L S.S.) or PTFE).
Max. viscosity 600 cst (mm2/s).
توضیحات:
Type
slide
Operation
pneumatic
Function
for control
Media
for water, for oil, petroleum, for gas, for air, for steam
Body$
flange, angle seat
Applications
for oil industry applications, for industrial applications, for the chemical industry, for the food industry, for the pharmaceutical industry, for the gas industry, for water treatment, for marine applications, for machine tools, power line, for vacuum, for the mining industry, for automobiles, for shipbuilding, for the paper industry, turbine
Material$
stainless steel
Other characteristics
standard, double-acting, ATEX, alcohol
DN
Min.: 15 mm(0.591 in)Max.: 50 mm(1.969 in)
Pressure
Min.: 0 bar(0 psi)Max.: 16 bar(232.1 psi)
Temperature
Min.: -10 °C(14 °F)Max.: 180 °C(356 °F)
