نام محصول:
دریچه توپ شناور

نام انگلیسی:
Floating ball valve

برند:
wenzhou domos fluid equipment co.,ltd

مشخصات:
Design Standard

Based on API 6D and Customer requirements

Pressure Rating

ASME 150 – ASME 2500

End Connections

As per API 6D standard

1) Anti-fire safe design: API 6FA, API607

2) Anti-static device

The static-conduction spring is set between the stem and the ball, the stem and the body. Thus static electricity is conducted to ground and system safety is secured.

3) Anti-blow out design

4) Free leakage of body Sealed construction

The connective position of valve body and bonnet is double sealed by gasket and O-ring, on this base, such factors as fire, high temperature, shock and uneven opening or closing of the torque all can’t induce external leakage

5) Low torque in operation

6) Double block&bleed(DBB)

7) Emergency sealing

8) Automatic body cavity relief

When the body pressure going up un-normally as the unstable factor, the trunnion ball valve downstream seat will be pushed by un-normal pressure, and the release the un-normally pressure automatically, it doesn’t damage to the sealing of upstream seat.

9) The valve structure can be 2 pieces or 3 pieces.

توضیحات:
Type
floating ball

Operation
with handwheel

Function
double block-and-bleed

Body$
flange, threaded, 3-piece, 2-piece, trunnion

Applications
for the chemical industry, for pipelines, for oil industry applications, for the gas industry, for marine applications, refinery, power line

Material$
alloy, stainless steel, carbon steel

Other characteristics
anti-static, fire-resistant

DN
Min.: 15 mm(0.591 in)Max.: 250 mm(9.843 in)

Pressure
Min.: 16 bar(232.1 psi)Max.: 420 bar(6,091.6 psi)

Temperature
Min.: -101 °C(-150 °F)Max.: 350 °C(662 °F)
