نام محصول:
دریچه تسکین فشار آب
نام انگلیسی:
Water pressure relief valve
برند:
Sapag Valves
مشخصات:
The SAPAG® Pressure Relief Valve owes its qualities to its original simplicity, the result of long theoretical studies and tests. Pressure relief valve is an effective way of protecting a pipeline against overpressures.
Applications
Overpressure protection for water distribution and treatment networks.
Technical data
Températures (°C): Ambiantes
Unidirectional design
Flange connections
Others : on request
Advantags
Total lack of guidance
Negligible inertia
Metal-to-metal seat
Reduced relief (variation in pressure during opening)
Small face to face
توضیحات:
Fluid
for water
Applications
for pipelines
Other characteristics
flange
Controlled pressure
Min.: 0 bar(0 psi)Max.: 77 bar(1,116.8 psi)
DN
Min.: 50 mm(1.969 in)Max.: 200 mm(7.874 in)
Flow rate
Min.: 0 l/s(0 us gal/s)Max.: 430 l/s(113.59 us gal/s)
