نام محصول:
تنظیم کننده فشار گاز

نام انگلیسی:
Gas pressure regulator HP 104

برند:
Hornung GmbH

مشخصات:
With the single-stage cylinder pressure regulator HP104 an inlet pressure of max. 200 bar can be reduced to an outlet pressure of max. 10 bar. Due to the integrated inlet pressure compensation, the outlet pressure is kept constant even with fluctuating inlet pressures. The HP104 is available in brass for non-corrosive gases and stainless steel for corrosive gases.

توضیحات:
Product
for gas

Technology
diaphragm, plug

Number of stages
single-stage

Output signal
analog

Material
chrome-plated brass, stainless steel

Applications
industrial, for medical applications, for analytical instruments, high-purity, for chromatography, cylinder, for chemical applications, for food applications, for pharmaceutical applications, for petrochemical applications, for aerospace applications, for automotive applications

Other characteristics
compact, with pressure gauge, miniature, high-purity

Pressure
Max.: 200 bar(2,900.75 psi)Min.: 0 bar(0 psi)

Flow
Max.: 10 m³/h(353.15 ft³/h)Min.: 0 m³/h(0 ft³/h)

Orifice diameter
0.125 in

Temperature
Max.: 70 °C(158 °F)Min.: -20 °C(-4 °F)
