نام محصول:
تنظیم کننده فشار هوا فشرده
نام انگلیسی:
Compressed air pressure regulator RPL series
برند:
SENGA
مشخصات:
In-line pressure regulators F/F tared without relieving – RPL series
Materials and components :
– zinc body
– other parts: brass, NBR, stainless steel
Application range: compressed air
– maximum working pressure: 18 BAR
– working temperature: -0°C / +60°C
Advantages: energy saving, unchangeable setting, no pressure gauge.
Settings: 1, 2, 3, 4, 5, 6, 6.5, 7, 8 bar
توضیحات:
Product
for compressed air
Number of stages
single-stage
Material
brass, stainless steel, zinc, NBR
Applications
industrial, high-pressure, for pneumatic applications
Other characteristics
line
Pressure
Min.: 0 bar(0 psi)Max.: 18 bar(261.07 psi)
Flow
Min.: 400 l/min(105.67 us gal/min)Max.: 800 l/min(211.34 us gal/min)
Temperature
Min.: 0 °C(32 °F)Max.: 60 °C(140 °F)
