نام محصول:
تقسیم جریان کارتریج
نام انگلیسی:
Cartridge flow divider FD50-44
برند:
HYDRAFORCE
مشخصات:
The FD50-44 is a screw-in cartridge, spool type flow divider/combiner valve.
Operation
The valve provides pressure compensated proportional division of inlet flow or combining of two return flows regardless of system operating pressure conditions. The valve is intended for use in mineral based or synthetic hydraulic fluids with lubricating properties.
Features
Choice of flow ranges.
Quiet, modulated response.
Wide operating flow range.
Accurate division or combination of flow.
Optional corrosion-resistant plating.
Industry-common cavity.
Fluids:
Mineral based or synthetic hydraulic fluid with lubricating properties
Fluid Viscosity Range:
7.4 to 420 cSt
Maximum Operating Contamination Level:
18/16/13 per ISO 4406
Unit Weight:
0.11 kg (0.25 lb)
Internal Wetted Surface Area:
164 cm² (25.4 in²)
Cavity:
VC10-4
10-size-4-way Cavities
Cartridge Installation Torque:
65 to 71 N-m (48 to 52 ft-lb)
Orientation Restriction:
None
توضیحات:
Technology
cartridge
Number of channels
4-way
Flow type
hydraulic
Operating pressure
345 bar, 1,034 bar(5,004 psi, 14,997 psi)
Flow rate
Min.: 2 l/min(0.53 us gal/min)Max.: 38 l/min(10.04 us gal/min)
