نام محصول:
انزوا
نام انگلیسی:
Isolation transformer TRD
برند:
Tescom
مشخصات:
Internal isolation transformer at input, Full controlled conventional rectifier, Smart control and high reliability with DSP (Digital Signal Processor)
GENERAL SPECIFICATIONS
Internal isolation transformer at input
Full controlled conventional rectifier
Smart control and high reliability with DSP (Digital Signal Processor)
Float charge, equalizing charge and boost charge modes
Automatic and manual charge modes
Low output voltage ripple and high reliability
2×16 character LCD display, showing measurements, status and alarm messages
Soſt start
Led displays for easy observation of rectifier status.
Audible alarm
Programmable current limitation
Operation as voltage source or current source
Calibration of measurements from front panel
Language selection from front panel. (English / German / Turkish / Dutch / Portuguese)
DC Low / High, Line failure, Over temperature, Short circuit protections
Ability to program all operation parameters (Password protected)
Programable alarm relay contact outputs (4 standart, up to 16 relays as option)
Possibility of monitor and control over RS232-RS485
Modbus communication
Earth leakage monitoring (DC leakage)
Log records with date and time stamp up the 200 events
OPTIONS
Active parallel (current sharing) operation up to 4 devices
Ability to monitor batteries and battery low alarm, even when the AC input fails.
Battery temperature compensation
Easy observation via analog gauges
Battery test with adjustable voltage and duration
Transducers for input / output voltage(s) / current(s) (4-20mA and 0-10V)
12 pulse option to limit input current distortion
Input Power / kVA / kW measurement
Internal cabinet light / cabinet anticondensation heater
توضیحات:
Type
isolation
Configuration
encapsulated
Applications
industrial, for medical applications, for data centers
Electrical characteristics
three-phase, voltage
Mounting
floor-standing
Other characteristics
control, rectifier, signal, galvanically-isolated
Primary voltage
190 V, 200 V, 380 V, 400 V, 415 V
Secondary voltage
12 V, 24 V, 48 V, 110 V, 220 V
Secondary current
Min.: 0 AMax.: 10,000 A
Frequency
50 Hz, 60 Hz
