نام محصول:
اتصالات هیدرولیکی
نام انگلیسی:
Hydraulic fitting Viega Smartpress
برند:
Viega GmbH & Co. KG
مشخصات:
Flow-optimised press connector system with press connectors made of gunmetal and stainless steel and multi-layer pipes. Multi-layer pipe, dimensionally stable, oxygen seal, colour: white. Press connectors with PPSU support body to ensure the leak tightness and mechanical strength of the connection. Safe and fast connection without widening or calibration of the pipe ends through O-ring-free press technology in all pipe dimensions. For protection pipes are equipped with pipe plugs. Suitable for concealed and pre-wall installations of riser pipes and floor installations.
Multi-layer pipe
Exterior colour white
Suitable for potable water and heating installations
Tools
The functional safety of Viega press connector systems depends primarily on the faultless condition of the press tools used. For the manufacture of press connections, Viega recommends the use of Viega press tools. Viega press tools have to be regularly maintained by authorised service partners.
Areas of application
Potable water
Heating systems
Rainwater
Compressed air systems
Note
The press connector system Viega Smartpress is suitable for the creation of potable water installations according to DIN 1988‑200 and EN 806‑2 in consideration of the selection of material in accordance with DIN EN 12502‑1 and according to the evaluation basis for metallic materials in contact with potable water of the Umweltbundesamt (UBA) (Federal Environment Agency). When used for other areas of use and when in doubt about the right selection of material, please contact Viega. Detailed information about applications, restrictions and national standards and directives can be found in the product information,
توضیحات:
Applications
hydraulic
Attachment
quick, crimp
Configuration
elbow
Norms
DIN
Material
stainless steel, bronze
Other characteristics
poppet, with end cap
Diameter
Max.: 63 mm(2.48 in)Min.: 16 mm(0.63 in)
Operating pressure
0.3 psi, 14.5 psi, 43.5 psi, 94.3 psi
