نام محصول:
اتصالات هیدرولیکی
نام انگلیسی:
Hydraulic fitting Fig.340
برند:
Hebei Jianzhi Casting Group Co., Ltd.
مشخصات:
BSP Pipe Fittings Union Taper Seat
Maximum Pressure: –
25 BAR (363PSI) (2.5MPA) CLASS 150
Maximum Temperature: –
200°C (392°F)
Tensile Strength: –
350MPA
Suitable Applications: –
Water, Oil, Gas, Petro-Chemical
Product Description
The taper union extrudes each other through the inner and outer conical inclined planes to form a sealing surface. Different from flat Union, flat Union adopts plane structure and realizes sealing surface through sealing ring.
Product Parameters
Size： – 1/8”-6”(DN6-DN150)
Standard: – EN10242 / ANSI / ASME B16.3 / DIN2950 / IS0 49 / NBR6943 / IS1879 / BS EN10242
Threaded Standard: – EN10226 / ASME B.1.20.1 / DIN2999 / ISO7-1 / ISO228 / IS554 / BS EN10226
Work Pressures： – PN25 / 2.5Mpa / 363PSI /CLASS 150 / 25Bar
Certification： – UL Listed /FM Approved /CE /ABNT /TSE /SNI /ISI
Technical Data
Maximum Pressure: – 25 BAR (363PSI) (2.5MPA) CLASS 150
Maximum Temperature: – 200°C (392°F)
Tensile Strength: – 350MPA
Hardness: – HB150 (Brinell)
Elongation Rate: – 10%
Suitable Applications: – Water, Oil, Gas, Petro-Chemical
Material: – Malleable Iron
توضیحات:
Applications
hydraulic
Attachment
threaded, ring
Norms
BSP
Material
iron
Other characteristics
standard, union
Diameter
Max.: 150 mm(5.906 in)Min.: 6 mm(0.236 in)
Operating pressure
25 bar(362.59 psi)
