نام محصول:
اتحادیه دوار آب
نام انگلیسی:
Water rotary union S series
برند:
ROTOFLUX s.r.l.
مشخصات:
These unions are available with two different balanced and microlapped sealing assemblies:
N Seal (Standard Sealing) with carbon graphite to carbide seals for application with filtered water.
D Seal (Heavy duty sealing) with carbide to carbide seals for poor filtrated water or abrasive fluids.
Fluid pressure over 8 bar is allowed only when the fluid is cool water at max temperature 125°F (50°C). Do not use the unions at max application limits without consulting ROTOFLUX.
توضیحات:
Medium
for water
Applications
for heavy-duty applications
Material
brass
Other characteristics
with seal
Rotational speed
750 rpm, 2,500 rpm, 3,000 rpm, 3,500 rpm(4,712.39 rad.min-1, 15,707.96 rad.min-1, 18,849.56 rad.min-1, 21,991.15 rad.min-1)
Pressure
40 bar, 50 bar(580 psi, 725 psi)
Nominal size
Max.: 2 inMin.: 0.25 in
