نام محصول:
موتور هیدرولیک دنده
نام انگلیسی:
Gear hydraulic motor
برند:
Zhejiang Dongzheng Motor Co., Ltd.
مشخصات:
800W HYDRAULIC OIL PUMP DC MOTOR GENERAL SPECS.
Voltage 24V DC
No-Load Speed 4400RPM
No-Load Current < 3.5A
Rated Output Speed 3100RPM
Rated Output Torque 2.45N.m
Rated Output Power 800W
Rated Current < 60A
Insulation Class F
Duty cycle S2 – 2min.
Customized shaft & front cover available upon request
Application: AGV, Automobile cab steering, Rising-lowering lifting system, Electric forklift, Lifting pump station, Hydraulic power leveling system etc.
توضیحات:
Technology
gear
Other characteristics
compact, industrial, high-pressure, for heavy-duty applications, flange-mount, high-torque, with gear reducer, with shaft couplings
Pressure
18 bar(261 psi)Min.: 1 bar(15 psi)Max.: 99 bar(1,436 psi)
Rotational speed
3,100 rpm(19,477.87 rad.min-1)Min.: 1,000 rpm(6,283.19 rad.min-1)Max.: 9,900 rpm(62,203.53 rad.min-1)
Torque
2.45 Nm(1.81 ft.lb)Min.: 1 Nm(0.74 ft.lb)Max.: 7 Nm(5.16 ft.lb)
