نام محصول:
دریچه
نام انگلیسی:
Ball valve Rubrik 13.15
برند:
PH Industrie-Hydraulik GmbH & Co. KG
مشخصات:
Body, Connecting Parts, Ball and Stem Stainless Steel, V4a (AISI 316)
Each PH ball valve is subject to an inspection for resistance, sealing
and special characteristics.
Inspection control certificates 3.1 B or 3.1 C per DIN EN 10204 can be
supplied on request against invoice.
Other materials as 254Smo or Hastelloy, etc. on request.
Ball Sealing: POM
Stem Sealing: NBR
The indicated working pressure PB is only valid for the standard version 4423.
Max. allowed pressure (PB) see at the data from the
compression couplings.
توضیحات:
Type
ball
Operation
lever
Function
for control
Material$
Hastelloy®, stainless steel
Other characteristics
standard, DIN
DN
Min.: 5 mm(0.197 in)Max.: 38 mm(1.496 in)
Pressure
350 bar, 400 bar, 500 bar(5,076.3 psi, 5,801.5 psi, 7,251.9 psi)
Temperature
Min.: -20 °C(-4 °F)Max.: 100 °C(212 °F)
