This new range of manual leadscrew tables is 20 to 35% more economical than the 309D range.

3 sizes with a new size 0:
This range is available in 3 sizes with rods Ø10, 12 and 16 for 4 standard strokes: 50, 100, 150 and 200 mm.
A new size 0 is inserted between the mini-table 309A0 and size 1 to obtain a more homogeneous range, especially in combination with XYZ tables because this range is also available as a lifting table.

The quality of the guidance is preserved:
The guide remains the same with 4 bronze bushings on 2 chrome steel rods. The play of the guide is then only a few hundredths.

Axial precision:
The ball bearing cage of the 309D range has been replaced by a bronze bearing which generates an axial play < 0.05 mm. In combination with the axial play of the trapezoidal screw nut, the axial accuracy in practice is between 0.05 and 0.15 mm. Interchangeability with the 309D and 309E range: The mounting holes of the plates and the carriage are the same as for the short tables Type 309D and the lifting tables Type 309E. Position display by ruler: The position is displayed either by means of a digital indicator or by a more economical version with a ruler on the base plate. The position can be locked in 2 places: The locking position is done manually by a clamping key. On this range, the clamping key can be placed above the control plate or at the end of the end plate depending on the available access. Anti-corroding version: On request, an anti-corrosion version is available with stainless steel and anodised aluminium parts. Orientation : XYZ Type : manual Number of axes : 2-axis, 1-axis, 3-axis Other characteristics : aluminum, compact, with position indicator, trapezoidal screw Stroke : Min.:
