Laser Triangulation Scanner with 10 to 50 deg arch rotating mirror scan
Non-Contact Measurement of distance and angle off all surfaces.
High temperature versions for surface temperatures of 1250°C
Measurement range options: 100 to 1300 mm
Stand off options: 200 to 1500 mm stand offs.
Radial and Polar resolution: 0.03 mm to 0.7 mm
Robust compact size of 310 x 190 x 64 mm
RS232 or RS422 (115200—230400 Baud) Serial Interfaces
Scan rate: 2kHz model with 300 or 600 scans/min 6kHz model with 450-1800 scans/min
6kHz Class 3R / 3B Laser Output Models with 450, 900 or 1800 scan rates
These MLS02 Laser Triangulation Scanners provide precision measurement in two dimensions. The measurement is performed by oscillating the triangulation plane by up to 50 deg. A fine collimated and focused laser beam is diffusely reflected from the surface of the material being measured and the internal CCD Camera records the image. This image is then processed by digital signal processor to calculate the radial distance from the centre of the mirror axis to the object surface as well providing an angular track off its position.
These Scanners are compact stand–alone units containing the optics, signal processing and camera unit. The Scanner view shown illustrates the scan line. The distance and angular values are provided at frequency of 2kHz or 6 kHz as a digital signal for application running under Windows using the MLS02 driver DLL.
Number of axes : XY
Applications : measurement, profile
Configuration : compact
Other characteristics : non-contact
Length : 310 mm (12 in)
Width : 190 mm (7 in)
Measuring distance : Max.:
