XST-500N is X-axis slide table with 500N capacity for both for tension and compression testing.
It enables you to align test sample very easily, improving test efficiency.
Combine it with a force gauge, attachment and test stand to complete a testing system.

Features
-Enables you to align test sample very easily, improving test efficiency
-Simply move the stage to set the sample at the desired position

Specifications
Capacity: 500N
Movable displacement: 70mm

Related Products
– Alignment stage for solder joints strength test SJS-100N-L/S
It is used to grip and fix samples, being mounted on a vertical test stand. It can adjust in the XY-axis direction finely and change the angle to 45 degrees or 90 degrees.

– XY-table XY-500N series
It is designed to move and adjust in the X-axis and Y-axis direction finely and easily.
– Chip peel fixture GT-10/20
It is deal for shear test of electric components with 500N Capacity.

– Vise Grip GT-30/2000N
It is used to grip and fix samples, being mounted on a vertical test stand. It is available in capacity from 250N up to 2000N.

– Chuck for Clamping Cap CCJ series
It is designed for gripping round shaped samples tightly by the 4 pins.

-Self-centering Vise Grip GTW-2500N
It is to be mounted to a vertical test stand for fixing sample. It is made of stainless in capacity up to 2500N.

We offer almost 100 of ready-made attachments to fit a wide range of force testing applications such as tension, compression, peel and COF test.
See our website for further information.

With our know-how accumulated over 70 years, we are confident in offering the best force measurement solution for your needs.
Please contact us for any enquiries.

Orientation : XY
Type : manual
Number of axes : 1-axis
Other characteristics : precision
Stroke : Max.:
