XMC Ultrascale+ Zynq® MPSoC Board with integrated FPGA

High-End CPU for Test and Application:

• XILINX® Zynq® Ultrascale+TM CG MPSoC, 1.3 GHz, Dual Core A53 Application Processor
Unit (APU) + Dual Core Realtime Processor Unit (RPU)
• Powerful Xilinx FPGA for flexible hardware design, integrated in CPU
• 4x GB-Ethernet, 1x serial interface
• More than 120 I/Os at connectors P4 and P6 configurable via FPGA as single ended (LVTTL) or 50 LVDS pairs

Health Features:

• Local voltage and temperature monitoring
• Watchdog
• Over temperature protection

Software Support:

• BSPs are available for Linux® and VxWorks®
• Example source code for the FPGA included in the Linux BSP
• Universal boot loader: “Das U-Boot”
• EtherCAT® Master available

Customization on Request:

• PMC instead of XMC
• CAN IP-Core via P4 or P6
• IRIG-B IP-Core via P4 or P6
• Other CPU-types of the Zynq UltraScale+ MPSoC family
• Extended temperature range
• RTC

!! Under development !!

Bus standard : XMC
Processor : dual-core
Other characteristics : embedded, for extreme conditions
