nanoVoxel-2000
Tube-sealed and Maintenance-free High-performance CT System
The nanoVoxel-2000 system is a high-performance imaging system that uses a sealed X-ray source. The X-ray source is maintenance-free and the sample chamber can accommodate large -size samples, is capable of expanding the in-situ loading device, and can be equipped with an objective lens coupling detector to realize high-resolution imaging at a long working distance.
Features and Advantages
● Tube-sealed X-ray source, no need for consumables and simple maintenance
● Large-sized chamber with good expandability
● High spatial resolution of 0.5μm
● Multiple scanning modes: spiral, offset, limited angle and others
Specifications
Resolution
Detectability : 1μm(Flat panel detector) / 50nm(Objective coupling detector)
Spatial resolution* : 3μm(Flat panel detector) / 500nm(Objective coupling detector)
X-ray source
Tube type :Sealed, Reflection
Voltage : 150KV
Detector1 (Flat panel)
Imaging area : 244mm×195mm
Pixel matrix : 1920×1536
Detector2 (Objective coupling detector), optional
Objecives : 4X、10X、20X
Sample
Maximum size : 400mm×300mm（diameter × height）
Maximum weight : 15kg
Equipment
Dimension : 1620mm×1100mm×1700mm（length × width × height）
Weight : 2400kg
Technology : X-ray, CT, 3D, NDT
Sector : industrial, multi-function
