Our XPIN Detector has a 625µm thick Si-PIN diode, an ultra-low-noise JFET, multilayer collimator, preamplifier, and is internally cooled with a two-stage thermoelectric cooler. Our detectors use DuraBeryllium® windows uniquely coated with DuraCoat®, which is corrosion resistant and ideal for harsh environments. All Moxtek detectors are encapsulated in vacuum enabling minimum detector temperatures. The XPIN is available with a 6mm2 or 13mm2 active areas. The compact sizes allow for design flexibility.
Features

Maximized Si-PIN resolution
High peak to background
High energy absorption
Close coupling of detector/ source, portable
Easy to integrate
Low power consumption
Low calibration maintenance
Lt-element identification, Corrosion resistant
Minimal stray peaks

Configurable Parameters

Active area (6mm² or 13mm²)
Configuration style (BT or XT)
XT mounting options (Angle Bracket (AB) or Heat Sink (HS))
BT adapter plate
Optional cables
Thin (8µm) window options

Detected entity : X-ray
