Worm gear reducerS series

FEATURES:
1. Modular design, compact structure
2. Low noise
3. Hollow output shaft with a keyed connection, shrink disk, or torque arm
4. Can be combined with other types of gearboxes

Rated Power:0.18kW~22kW
Max. Torque:90~4000N.m
Gear Arrangement: Helical-worm Gears
Shafts Position: Right Angle
Ratio:10.27~230.48
Installation Form: Foot, Flange, Shaft Mounted

Rated Power:0.18kW~22kW
Max. Torque:90~4000N.m
Gear Arrangement: Helical-worm Gears
Shafts Position: Right Angle
Ratio:10.27~230.48
Installation Form: Foot, Flange, Shaft Mounted

Type : worm, helical
Shaft orientation : right angle
Torque : 200 – 500 Nm, 100 – 200 Nm, 50 – 100 Nm, 1 – 2 kNm, 2 – 5 kNm, 500 – 1000 Nm
Shaft configuration : hollow-shaft, solid-shaft
Performance : low-noise
Other characteristics : compact, modular, flange, shaft-mounted, foot-mounted
Power : Min.:
