The R Series is a precision worm gear reducer developed specifically for driving our SANDEX units. It is designed to be mounted directly to the input shaft for a compact, accurate, lossless transfer of power. Adjustable preload minimizes backlash for smooth, even rotation. Sankyo reducers are fitted with responsive, durable clutch and brake units for frequent start/stop operation. These units also use the universally accepted Newman worm to ensure the best performance at all times.
BACK TO TOP
Features
Wide Product Lineup
Reduction ratio: 5 to 50, Maximum input speed: 1800 rpm
Compact
Designed to mount directly on the input shaft of a SANDEX for minimal footprint.
Optional Clutch and Brake Units
All reducers can be fitted with responsive, durable clutch and brake units.
Various Mounting Configurations Available
In addition to the different mounting positions for the housing, the mounting direction of the clutch and brake unit can also be specified.

Type : worm
Shaft orientation : coaxial
Torque : 100 – 200 Nm, 50 – 100 Nm
Performance : low-backlash, precision
Applications : for shaft
Other characteristics : mounted, compact
Rotational speed : 1,800 rpm (11,309.73 rad.min-1)
Power : Min.:
