INTERCHANGEABLE SPINDLES:
Choice of4 spindle diameters- 7″ 1-1/4″. 1-3/8″, 1-1/2″ or choice of metrk
sizes- 25mm, 30mm, 35mm, 40mm. Spindle has MK5 taper lo ensure
precision fitting and allow quick changeover of another spindle.
QUICK CHANGE SPINDLE SPEEDS:
The spindle is driven by four-speed pulley for spindle speeds of 3C00,
4500, 7500 and 10000 RPM. Change of speed is quickly and easily
accomplished by simply loosening a lock lever, and shirting the
complete assembly.
FOOT SPINDLE LOCK:
The spindle is foot treadle locked for convenient cutter and spindle
change.
FOOT SPINDLE BRAKE:
Treadle plate provides instant stop of the running spindle after power
has been turned off.
REVERSIBLE SPINDLE ROTATION:
The spindle is reversible to ensure safe rotation in clockwise or
counter-clockwise direction.
ROUTING OPERTION:
Optional collets can be supplied to enable the shaper do a routing
application. Piovides excellent flexibility all in one shaping system.
TILTING SPINDLE:
The tilting spindle provides angle cutting from -5″ ~ 90″ -4-45″. Spindle
tilting handwheel is located at front within easy reach. A tilt scale Is
attached for accurate angle setting. A locking handle anchors spindle
into fixed angled position.
Applications : for wood
