FEATURE:

MULTI FUNCTIONS:
1.By inputting the wire diameter , workpiece material & thickness , and desired surface finish , optimum
cutting conditions are automatically generated from memory.
2.It is possible to carryout the machining conditions of second, third, fourth cutting; the second cutting easily obtained by using the retrace function.

WIRE BREAKAGE RECOVERY:
1.In case of wire breakage during machining, just press button and wire returns to start point.By ressing button , wire will move rapidly retracing machining path back to that point.

WATER COOLING CONTROL:
1.The inverter control for pump and water coolant unit keep the thermal balance on every part of the machine and lowexpansion of material in submerged machining.

WIRE FEEDING:
1.Operator has only to pass wire through lower nozzle guide and wire will be taken by the water-jet wire-collecting device to the collector.
2. Equipped power mos-transistor circuit system. max. out-put current 25 ampere .

REMOTE CONTROL BOX:
1.For the convenience of operator , the remote control box contains many of the functions required for set-up.
2.PC-base designed, CNC Controller with IPC, used G.M. NC-code edit. standard with CF CARD and RS-232c interface.

Type : wire
Other characteristics : CNC, for micro-machining
X travel : 300 mm, 400 mm, 500 mm, 600 mm, 800 mm (12 in)
Y travel : 200 mm, 300 mm, 400 mm, 500 mm (8 in)
Z travel : 150 mm, 250 mm, 300 mm (6 in)
