Water pumpEtachrom L

Etachrom L
Main applications
Biogas
Breweries
Building services
Cooling water and condensate
Energy
Food and beverages

Design
Horizontal single-stage annular casing pump, with ratings and main dimensions to EN 733, with replaceable casing wear rings and motor-mounted variable speed system. With KSB SuPremE, a magnetless synchronous reluctance motor of efficiency class IE4/IE5 to IEC TS 60034-30-2:2016, for operation with the KSB PumpDrive 2 or KSB PumpDrive 2 Eco variable speed system without rotor position sensors. Motor mounting points in accordance with EN 50347, envelope dimensions in accordance with DIN V 42673 (07-2011). ATEX-compliant version available.

Application
Cleaning systems (bottle rinsing, crate washing, etc.), water treatment plants, water supply systems, fire-fighting systems, spray irrigation systems, irrigation systems, drainage systems, hot-water heating systems, air-conditioning systems, industrial washing plants, general industry, disposal of paint sludge, surface treatment

Fluid : water, paint, condensate, oil
Operation : electric
Technology : centrifugal
Domain : industrial, for wastewater treatment, for the food and beverage industry
Applications : handling, cooling, irrigation, drainage, washing, cleaning, transport, spraying, surface treatment, rinsing
Mobility : stationary, mobile
Protection level : ATEX
Other characteristics : single-stage, heating, with variable-speed controller
Flow : Min.:
Pressure : 12 bar (174.045 psi)
Head : Min.:
Power : 45 kW (61.18 hp)
Fluid temperature : Min.:
