Vertical injection molding machinePHA-8

– Press MECAMAQ for injection, It has a power of 8 Tm.
– The low table is of 800 x 700 mm and the superior 650 x 400 mm, the plate ejector is of 700 x 350 mm.
– The maximum opening between tables 1.200 mm, and the principal cylinder has a course of 900 mm.
– Auxiliary connections for holes, mouthpieces and closing of the molds.
– ​All the movements are controlled for encoder linearly and are programmable by means of tactile digital screen.
– Chassis made of 4 cylindrical columns of Ø80 mm and protections for doors with switches and photoelectric barriers of safety.

Closure : vertical
Operation : hydraulic, electric
Other characteristics : two-platen
