Boston Gear’s spur gears, which are designed to transmit motion and power between parallel shafts, are the most economical gears in the power transmission industry.
We offer both 14 1/2° and 20° PA (pressure angle), involute, and full-depth system gears. 20° PA is generally recognized as having a higher load carrying capacity; however, 14 1/2° PA gears are used extensively as well. This is because the lower pressure angle reduces change in backlash due to center distance variation and concentricity errors. The 14 1/2° PA also provides a higher contact ratio for smoother, quieter operation.
Boston Gear spur gears are available through our Guaranteed Same Day Shipment from our world class manufacturing center in Charlotte, NC. Many different gears with a variety of bore sizes, keyways, and setscrews are routinely in stock, but if the particular bore/keyway/setscrew combination needed is not readily available, our machining experts can alter any non-hardened gear and ship it within 24 hours. Just ask!
Transmits motion and power efficiently between parallel shafts.
Our 20° PA spur gear has a high load-carrying capacity for enhanced performance.
The 14 1/2° PA spur gear offers smooth, quiet operation.
Spur gears are manufactured in Delrin, non-metallic, brass, steel, and cast iron materials for maximum versatility.
Non-metallic (phenolic – grade C) material provides quiet, corrosion resistant operation.

Type : spur
Teeth : straight-toothed
Other characteristics : shaft, shaft
