• Cost effective gearmotor
• NEMA 17 step motor with gearhead
• 10:1 ratio amplifies step motor torque
• Offset parallel output shaft
• High torque design
• Strong composite gearhead body

The 17071-2-10S stepper gearmotor is a NEMA 17 step motor and 10:1 gearhead pre-assembled for ease-of-use and greater output torque than the step motor by itself.

Part Number: 17071-2-10S
Frame Size: NEMA 17
Motor Type: Gearmotor
Motor Length: 2.52 inches
Number of Lead Wires: 8
Lead Wire Configuration: flying leads, no connector
Lead Wire/Cable Length: 12 inches
Lead Wire Gauge: 26 AWG
Step Angle: 1.8 deg
Bipolar Series Current: 0.85 A/phase
Bipolar Series Resistance: 6.6 Ohms/phase
Bipolar Series Inductance: 14.4 mH/phase
Bipolar Parallel Current: 1.70 A/phase
Bipolar Parallel Resistance: 1.7 Ohms/phase
Bipolar Parallel Inductance: 3.6 mH/phase
Unipolar Current: 1.20 A/phase
Unipolar Resistance: 3.3 Ohms/phase
Unipolar Inductance: 3.6 mH/phase
Rotor Inertia: 9.02E-04 oz-in-sec2
Integral Gearhead: Yes
Weight: 1.16 lbs
Insulation Class: Class B (130 ºC)
Maximum Radial Load: 4.5 lbs
Maximum Thrust Load: 3.5 lbs
Shaft Diameter: 6.35 mm (0.250 inch)

Motor type : stepper
Shaft orientation : parallel-shaft
Shaft configuration : solid-shaft
Torque : 0.5 – 1 Nm
Performance : high-torque
Operating temperature : Min.:
