Speed measurement circuit board

With the RASdelta speed board, you record precise, multi-channel and digital speed measurement data for all transmission, control and auxiliary drive tests. It is the basis for torsional vibration analysis. The data is acquired via magnetic, angular equidistant scanning, an incremental encoder or a laser.

Input channel
2, galvanically isolated
Resolution
12,3 GHz
Connector
8-pin Lemo
Maximum (output) pulse frequency
20 MHz
Overvoltage protection
+/- 80 volt
Measurement modes
Speed, frequency, duty cycle or on/off-ratio
Other
• – Internal pulse divider (optional / required, if > 2 MHz)
• – Variable trigger levels from 0,3 to 4,5 volt
• – Trigger on falling, rising or both edge
• – Power supply for external electronics: + 5 volt and + 12 volt
• – 5 watt per channel
• – Short circuit protected

Function : for speed measurement
