Single-axis accelerometer746

Top exit, underwater accelerometer, 10ft integral J6 cable, titanium case, case isolated, 100 mV/g

Features
Hermetically sealed
Titanium case
650 psi pressure rating
IP68 rated integral cabling for submerged applications

Included accessories
SF1 mounting stud

Specifications

PARAMETER
VALUE

Sensor output
Dynamic vibration (IEPE)

Sensitivity
100 mV/g

Sensitivity tolerance
±5 %
Frequency response
1 Hz – 15,000 Hz

Mounting Thread
10-32 tapped hole
Connector style
Integral cable

Connector orientation
Top exit

Full-scale range
80 g peak

Resonance frequency
30 kHz

Temperature range
–50°C to +80°C

Weight
45 grams

Hazardous area approvals
Non-approved

Number of axes : single-axis
Technology : piezoelectric
Other characteristics : high-sensitivity, IP68, for general purposes, underwater
Frequency : Min.:
