Seawater pumpJEX11xCx series

Descriptive

Technical data:

Pump with low-voltage motor, stainless steel 316 body
Liquid foods, industrial and chemical liquids without solid impurities.
Voltage: 12 Volts (JEX114C1), 24 Volts (JEX114C2, JEX112C2)
Rotation speed: 2000 rpm, 1400 rpm
Power: 0.37, 1.12 (JEX112C2)
Voltage: 12 V dc (JEX114C1), 24 V dc
Current: 32 A (JEX114C1), 20 A (JEX114C2), 45 A (JEX112C2)
Orifice Ø: 1″1/4 M, 1″1/2 M (JEX112C2)
Max. TDH: 10 metres, 22 metres (JEX112C2)
Specifications and advantages:

Electric side-channel pump with DC motor

Characteristics

More Information
FLUID Water with low solids contect, Seawater, Diesel
TECHNOLOGY DC, Side channel
ATEX No
PUMP Bare
MAX FLOW RATE 3,5 m3/h – 7,2 m3/h
ORIFICE 1″1/4 M, 1″1/2 M
MATERIALS Stainless steel 316
MECHANISM Stainless steel 316

Fluid : for seawater, for chemicals, for juice, for wine
Operation : electric
Technology : side-channel
Domain : industrial, chemical
Material : stainless steel
Flow : 3.5 m³/h, 7.2 m³/h (123.60133 ft³/h)
Head : Min.:
Power : 0.37 kW, 1.12 kW (0.5 hp)
