DIAVITE DH-10 TOUCH
One instrument for tracers without and with skid
With the DIAVITE DH-10 TOUCH you can work with tracers without and with skid. The entire DIAVITE tracer range is available to you with just one device!
On the 10.1“ Full HD Touch Display you will find all controls for a quick and easy measurement. You define the measurement (measuring length, filter, speed, etc.) and save it with an image and corresponding protocol.
Via the menu or a barcode scanner you select the program and execute it. The protocol is then printed via LAN (WLAN/ Bluetooth) or stored on the server, USB stick on the previously defined path. You have the choice whether to save in PDF, CSV or TXT format. A statistical evaluation of several measurements can also be recorded.
ROUGHNESS MEASUREMENT
High-precision roughness measurement instrument for universal use in workshops and measuring rooms
Automatic calibration
Measuring sections all adjustable 0.5 to 15.0 mm
Adjustable measurement speed
Calibration of up to 8 tracers
Saving measurement conditions with image
Many tracers for almost all measuring tasks, including customer specific solutions
Simple, multilingual menu guidance
Tolerance display for exceeded measurement values
Accessories for many applications, crucial when working with tracers without skid
TECHNICAL DATA – DIAVITE DH-10-TOUCH
Parameters roughness – ISO/DIN: Ra, Rz (DIN), Rmax, R3z, Rt, Rq (RMS), Rk, Rp, Rv, Rpk, Rvk, MR1, MR2, RPc, C1, C2, contact ratio Rmr, C0, Cz, V0, Rdg, RL0
JIS: Ra (JIS), Rz (JIS)
ISO 12085: R, AR, Rx
Parameters profile – ISO/DIN: Pa, Pz, Pt, Pq, Pmr, PPc, Pmax
Measurement ranges – Ra, Rq: 0 – 20.00 μm | 0 – 800 μin
Measured value : roughness
Technology : contact
Other characteristics : with display, high-precision, USB, Bluetooth
