Mikron Multistar
The versatile machining system for small precision parts
The Multistar transfer machine is well known for its wide range of applications. Parts for injection systems and gas burners, connectors for the electronics and electrical industry as well as components in the area of surgery, communications and audio-video are some of many ideal Multistar workpieces.
Multistar machines parts made from materials such as steel, non-ferrous metals or aluminium, in the diameter range from 0.4 to 35 mm with maximum lengths of up to 65 mm.
High-precision rotary transfer machine with 24 stations
Full CNC or mechanically actuated versions
Highly accurate manufacturing and repeatability
When it comes to high-volume production, Multistar is the best partner!
Available with from one to four simultaneous cycles, depending on part complexity and required volume
Capacity of up to 150 parts/min in single-cycle operation and up to 600 parts/min in four-cycle mode
The best of productivity with full CNC flexibility
The ideal solution for cost-effective batch production of a few hundred to many thousand parts from materials such as alloy steel, brass, titanium or aluminium – with maximum dimensions of Ø 35 mm and maximum lengths of up to 65 mm.
Up to 44 machining units operating simultaneously at 24 stations, assuring a very high output rate.
100% programmable and 100% versatile – all axes electronically controlled for fast changeover
Capacity of up to 30 pieces/minute
High precision
Type : rotary
Control type : CNC
Other characteristics : machining, precision, high-accuracy, programmable, 3/5-axis
