The basic version of the Sliding table HST 150 with a ball locking bolt consists of:
a baseplate with mouning bores for all GECHTER presses
a ball-bearing guide with carriage
a hardened and ground formed anvil
a mounting plate with 4 mounting bores
a stopping plate with adjustable fi xed stop
an oil shock absorber
a handle for moving the sliding table in and out
a ball catch for adjusting the work position
The Sliding table HST 150 RB consists of the same components as the basic version from pos. 1 to 7. In pos. 8, it is equipped with a mechanical locking bolt for the absorption of lateral forces (manual operation).
The Sliding table HST 150 PPR is equipped with a pneumatic locking bolt for the absorption of lateral forces, and the back an forth motion of the table
is also performed pneumatically. Operation is only feasible with SEM or external control.
Options : for presses
