Precipitation sensor

The precipitation sensor gives a qualitative measurement of precipitation :

• the intensity of precipitation : None, Little, Average, Strong, Very Strong
• precipitation : Rain, Rain/Snow, Snow

Its operating principle is based on an infrared beam that is broken by the raindrops or snowflakes.

Mechanical characteristics:
Dimensions : 185 x 165 x 85 mm
Weight : 400 g

Main features:
Alimentation : 10 to 30 volts DC
Maximum power consumption : 50 mA
Sensitive measurement element : Infra-red LED
Operational temperature : from -40°C to + 80°C
Connection : quadrupole plug connector

Type : relative
Mounting : duct-mount
Applications : air, for HVAC
