Imagine having a compressor capable of great performance and endowed with extraordinary solidity. What would all this be without absolute simplicity in managing it?
We believe that innovation is for this: to make everything simpler.

2-stage high pressure pumping unit

Monobloc in aluminum,
Gooseneck in forged steel
with forced lubrication on 2nd and 3rd stage cylinders by gear pump
Oil filtration.
Oversized interstage cooling pipes
Double final separator
Without maxifilter filter system
Forged aluminum connecting rods
Main roller bearings
Roller connecting rod bearings
2nd stage cylinder in aluminum with hard nicasil coating
2nd and 3rd stage slide guide cylinders in aluminum with hard nicasil coating
3rd stage cylinder in special treated steel.
Stainless steel intake and exhaust valves
Interstage cooling pipes in stainless steel
Separator after the 2nd and 3rd stage
Safety valves after each stage
Oil level sensor

3-stage pumping unit with gas recovery (zero Loss version)

With service stage that recovers the gas that leaks towards the monoblock and re-introduces it in the 2nd stage
Monobloc in aluminum,
Gooseneck in forged steel
with forced lubrication on 2nd and 3rd stage cylinders by gear pump
Oil filtration.
Oversized interstage cooling pipes
Double final separator
Without maxifilter filter system
Forged aluminum connecting rods
Main roller bearings
Roller connecting rod bearings
2nd stage cylinder in aluminum with hard nicasil coating
2nd and 3rd stage slide guide cylinders in aluminum with hard nicasil coating

Technology : piston
Type : air, nitrogen, hydrogen, helium
Power source : electrically-powered
Portability : stationary
Lubrication : oil-lubricated
Other characteristics : low-noise, high-pressure, high-performance, two-stage, three-stage, with booster, belt-drive
Pressure : Max.:
Flow : Max.:
Power : 4 kW, 5.5 kW (5.44 hp)
