Layout marking is a bottleneck in many operations. The Voortman V704 beam layout marking machine improves efficiency and accuracy and leaves the days of layout marking bottlenecks behind. In a fully automated production line, the V704 increases output by offloading other machines that can also mark. It can be added to a production line to mark as much as possible automatically, making assembly and welding easier and faster with no chance of error.

FOUR SIDE LAYOUT MARKING
The Voortman V704 marks all four sides of the product in one pass, saving time and costs in the assembly area of your workshop. When marking only one side, assembly employees still need to perform manual measurements on the remaining sides of the profile. The machine can indicate product numbers, contours, welding information and detailed part numbers for plates and angles that will be welded to the profile. The marking tool has minimal maintenance required because the tool is driven by compressed air. Carbide tips are quick and easy to replace.

ACCURATE POSITIONING
Every profile and product is measured, and the position is tracked and maintained throughout processing with the roller feed measurement system in the V704. Marks are placed in exactly the right position as determined in the DSTV file or the file in VACAM software. When integrated in a complete production line, all processes are split up between capable machines in the system and positioned correctly, so the combined product is exactly according to the product description. Measuring is faster and more precise with the V704 than the manual process.
