Mid-infrared LEDL15893-0330C

Peak emission wavelength: 3.3 μm
The L15893-0330C is a mid-infrared LED with a 3.3 μm peak emission wavelength. It is a product that has been achieved using Hamamatsu unique crystal growth technology and process technology. It is a suitable light source for CH4 detectors.

Features
– High output
– High-speed response
– High reliability
– Low power consumption
– Surface mount type ceramic package

Specifications
Package : Ceramic
Package Category : Surface mount type
Peak emission wavelength (min.) : 3100 nm
Peak emission wavelength (typ.) : 3300 nm
Peak emission wavelength (max.) : 3400 nm
Spectral half-width (typ.) : 400 nm
Radiant flux (typ.) : 1.3 mW
Forward voltage (typ.) : 2.7 V
Measurement condition : Typ. Ta=25 ℃, unless otherwise noted

Spectrum : mid-infrared
Configuration : square
Mounting : surface-mount
Other characteristics : high-speed, low-power
