In its sensor housing, the combiSENSOR combines an eddy current displacement sensor and a capacitive displacement sensor. This unique sensor concept enables one-sided thickness measurement of electrically non-conductive materials on metallic objects. Its field of application is the thickness measurement of plastic film or of plastic coating on metal plates. Connected to the sensor via a cable, the controller processes and calculates the signals in order to put them out via interfaces.

Calculation of the two sensor signals provides compensation of mechanical changes such as thermal expansion, deflections or eccentricity in the measurement device. Due to the redundancy of this combined sensor principle, the measured thickness value remains unaffected by any changes in the measurement setup. Due to the high temperature stability, the combiSENSOR provides high measurement accuracy even with fluctuating temperatures.

Possible applications:
•Non-contact thickness measurement of plastic films
•Non-contact thickness measurement of coated metals
•Measurement of the applied adhesive
•Lateral profile due to a traversing axis

Number of axes : 2-axis
Applications : profile, for measuring, shape measurement, for coordinate measuring machines, for adhesive application, for small parts, for pipes, for surface inspection, for welding inspection, for pipe inspection, object measurement, for production lines, gap, for robotic dimensional inspection, for soldering inspection, for quality control, for robots, for girth weld inspection, for detection, for medical applications
Technology : laser line triangulation, optical
Configuration : compact, in-line, fixed
Other characteristics : high-speed, high-resolution, high-precision, Ethernet, IP67, with blue laser diode, with integrated electronics, automated, non-contact, robotic
Length : 112 mm (4 in)
Width : 96 mm (4 in)
Measuring distance : Min.:
