Manual pressLabManual

•The LabManual 300 is a manually operated press especially designed for basic pressing operations and moderate use.
•2 column press frame: extraordinarily high parallelism and easy access to press area
•Extremely accurate temperature distribution
•accurate pressing by a highly controlled pressure build-up
•precise force distribution over the full platen surface thanks to the rigid design
•Fixed upper platen
•moveable lower platen
•Compact
•Easy to operate
•High safety level
•Service friendly
•Several options available e.g. cooling, platen material

LabManual

press range kN 0-300
platen size mm 320×320
specific pressure N/mm2 2,93
amperage A 16
max. temp. °C 300
voltage V 230
length mm 500
width mm 500
height mm 800
weight kg 275

Operation : manual
Function : forming, compression, test
Other characteristics : with heating plates, bench-top, laboratory, for plastics, rubber, for composite materials
Opening : Min.:
Force : 300 kN
