LED illuminatorSATURN

LED illumination and Fiberoptics

SATURN – LED ring light for high level illumination

SATURN is a LED illumination used for the optimal light contrast for stereomicroscopes. Made of premium black-anodized aluminium housing, SATURN features 80 highlighted LEDs, which can be divided into 8 segments.
With the built in joystick on the light controller, you have the possibility to switch between each segment and its combinations. With the brightness wheel on the light controller, every single segment can be dimmed separately. It also features a memory function, where you can store 9 different illumination settings, which can be easily called up later.

With SATURN, you have two ways to take control over your ring light.
Joystick and brightness wheel on the light controller, but you also have a built in USB interface, which gives you the possibility to adjust the ring light using your PC.

Dimensions of the ring light are – outer diameter of the ring is 114mm, the inner diameter is 66mm. With the adapter rings available, you can use the ring light for objectives with diameters from 58mm to 66mm.

VENUS – Compact ring light
Also made of premium black-anodized aluminium housing, VENUS ring light also features highlighted LEDs, which can be dimmed with a brightness regulator on the light controller.
Although VENUS ring light is not divided in segments, with its alternatively 40 or 80 highlighted LEDs, it creates a very bright and homogenous illumination of the object.

Also available:
MARS – fiberoptic coldlight source for microscopy and general illumination

Illumination technology : LED
Spectrum : white
Other characteristics : compact
Technical applications : for microscopes, inspection
