Our rotary table laser marking systems allows the operator to load one side of the fixture table while the other is inside being processed. This configuration increases parts per hour by reducing downtime for loading/unloading parts. Systems are designed for customer specific parts and processes (mark, cut, drill, weld).

This specific system has a CO2 laser and two barcode readers for pre-process automatic data entry and post-process validation of the marks. This combination increases the size of the system. We have smaller fiber laser systems for basic part marking of small parts.

Features:
– 2, 3, or 4 Position Table (Overall design and size will vary)
– CO2, Fiber, UV, or Green Laser Sources Available
– Safety Light Curtain and Touch Activation Sensors
– Optional Barcode Readers for Mark Verification
– CDRH Class 1 Laser System
– Fume Extraction System
– Windows® 10 PC with Mouse and Keyboard, Monitor, and Ergonomic Arm
– Customization Available

Systems are designed and built in the USA with 24/7 worldwide support and service.

How we do quotations: Our business does not build off-the-shelf systems. Meaning, each system is engineered for specific processes and will most likely vary in size, shape, and price. We look at your material and requirements, and we design a solution around those parameters. If one of our standard proven designs will work, we start from there.

Technique : laser
Material : metal, plastics, paper, wood, aluminum, for hardened materials
Applications : for tubes, for jewelry, for bearings
Other characteristics : automated, programmable, with touch screen, deep marking, traceability, for flat and cylindrical objects, computer-controlled, vision system, with rotary table
