Infrared LED

PD-LD offers LED-based WDM-style bi-directional transmitter and receiver modules operating in the 850 and 1310nm optical windows. These devices, part number PW85ST, are designed to simultaneously transmit and receive over a single optical fiber at frequencies from DC to 200MHz.

Dual wavelength bi-directional modules replace the need for a multimode fiber coupled LEDs, a fiber coupled PIN photodiode, a discreet fiber optic WDM and a second stage optical isolator. The bi-directional modules combine all of these optical functions and relieve the user of having to fusion splice several discreet units together and then squeeze them onto their PCB.

Features
Output Power of –16dBm typical
-40°C to 85o Operating Temperature Range
850 nm LED Source
Low Internal Cross Talk
Low Noise InGaAs PIN Photodiode Receiver
Compact, rugged construction
Low Power Consumption
ST Board or Panel Mount Receptacle
Replaces Discreet Components
Class 1 Eye Safe Device%

Spectrum : infrared
Configuration : compact
Other characteristics : bi-directional, multimode
