IML EASYCORE FOR IML MOULD SHAPING IN IML ROBOT APPLICATION
Simco-Ion’s patented IML charging technique for use in IML robot applications(example here) is even more versatile with the IML Easycore 2 component resin for construction of IML cores. The conductive IML Mould resin can be used to transfer the power of the Simco-IOn IML Generators to the IML Labels. Even very complex and small cores can be constructed with the 2 component resin. The resin is specially developed by Simco-Ion to have the perfect electrical and mechanical properties for use as an IML core. All mechanical operations s.a. drilling, grinding, milling etc are possible to make the core to the perfect shape and size. The IML Easycore comes in duo-packs consisting of the resin and the correct amount of hardener. A video showing the process of mixing the Simco-IOn Easycore Resin can gbe found here. Package sizes of 250 g are available. Please checout your local supplier of Simco-Ion IML material here.

Difficult shapes possible
Easy construction
Grinding, milling and drilling possible
Perfect electrical properties

2 component resin for construction of IML cores
Even very complex and small cores can be constructed
Comes in duo-packs consisting of the resin and the correct amount of hardener
Available in 250 and 500 g

Pot life 150g
20 – 40 minutes

Gel time 150g mass @ 25°C
40 – 80 minutes

Minimum cure
Full cure

Cure schedule
24 hours @ 20°C | 1 week @ 20°C

Cure schedule
2 hours @ 60°C | 4 hours @ 60°C

Cure schedule
1 hours @ 80°C | 2 hours @ 80°C

Flame retardant
Yes

Shore A hardness
78

Electric strength
16 kV/mm

Applications : for IML core-making
Other characteristics : two-component
