Depending on the configuration, the HOT CUTTING MACHINE GM70 can cut:
1. Cold with tempered steel scissor blades and self-sharpening with maximum cut-off light of 70 mm;
2. Hot with a blade heated by low voltage electrical resistance and the cutting of HOT CUTTING MACHINE GM70 is done by thermosetting (suitable for synthetic materials only) with a cutting light of 70 mm and can be equipped with an automatic cutting device inclined;
3. With both cutting groups, which can be used separately, selectable directly from the electronic programmer.
Technical features:
DIMENSIONS : 550X1300X480 (h) mm
WEIGHT : 46 Kg
ALIMENTATION : Monophase 230 V Triphases 400V 50/60Hz 800 W Hot Cut
POWER : 1 HP
STRIKE : 40 mm
CUT LENGTH : From 0,1 mm Till to 65 mm
CUT LIGHT : Hot 70 mm – Cold 70 mm
IN ADDITION TO THE SALE OF THE EQUIPMENT GM AUTOMAZIONI IS ABLE TO PROVIDE MANY SERVICES, INCLUDING:
• – WIDE RANGE OF PRODUCTS FROM OUR PRODUCTION AND THE BEST BRANDS ON THE MARKET
• – CUSTOMIZATION OF EQUIPMENT AND PLANTS TAILORED TO THE CUSTOMER’S NEEDS
• – DESIGN AND REALIZATION OF SPECIAL SYSTEMS
• – TECHNICAL ASSISTANCE AT OUR HEADQUARTERS OR AT THE CLIENT’S HEADQUARTERS
• – SPARE PARTS FOR ALL MACHINES OFFERED
• – COURSES AND DEMONSTRATIONS TO USE THE EQUIPMENT BETTER
• – INSTALLATION AND TRAINING OF THE STAFF EMPLOYED BY THE MACHINES
• – VERIFICATION OF FEASIBILITY ACCORDING TO CUSTOMER REQUESTS
• – FREE SAMPLES BY TESTING DIRECTLY ON YOUR SAMPLES
• – DEMONSTRATION OF THE EQUIPMENT AT OUR HEADQUARTERS OR AT THE CLIENT’S HEADQUARTERS
• – COURSES AND SEMINARS FOR IN-DEPTH INFORMATION ON THE USE OF EQUIPMENT
• – SCHEDULED MAINTENANCE TO AVOID EXPENSIVE MACHINE STOP
Technology : knife
Product handled : cable
Control type : CNC
Other characteristics : automatic, cold, hot
X travel : Min.:
