The Hektros BioSpir is a unique gas handling device, specially developed for gassing cell-cultures.
It combines a pressure-reducing valve with a calibrated fixed-flow regulator to provide a constant gas flow of 10 ml/min. The BioSpir was designed to meet the demands of the Hi5 Live Cell Imaging incubator as well as to provide a high-quality and easy-to-use gas valve for scientific applications.
• open/close to operate the valve
• drain position to quickly empty the valve before disconnecting
• no tools necessary for connecting or disconnecting
• 10ml/min
• Custom
Attention Pressure cylinder connection is country-specific!
Standard Bottle Connector:Test gas UNc, cylinder connection (DIN M19x1,5 LH.)
Gas Mixture:Air/ Air + 5% CO2 or similar gases
Standard:ISO 2503:2009
Input pressure:P1 230 bar
Class:cl.0
Output flow:Q1 10 ml/min +/- 10%
Input Connection:Country specific (DIN – UNI – AFNOR …)
Output Connection:Quick Coupling DN 2.5
Pressure relief valve:7 bar
Body material:Aluminium 7075 – Ni-Plated
Product : gas
Technology : piston
Number of stages : single-stage
Pressure : 230 bar (3,335.87 psi)
Orifice diameter : 2.5 mm (0.1 in)
Flow : 10 l/min (2.64 us gal/min)
