Floor-standing AC Charging Pile
Application
AC charger

Product Introduction
CPA series AC charger provides controllable single-phase AC for electric vehicle’s OBC, intelligent industrial control technology with multiple protection functions, user-friendly interface, automated charging control, provide RS485 serial port and GPRS wireless and other communication interfaces and real-time communication in the monitoring background, change the PWM duty following the server instruction, limit the charging power, and detect the connection status of the charging cable in real time to ensure the safety of people and vehicles during the charging process.

Technical Parameter
Rated voltage – 220V AC
Working frequency – 50Hz
Working current – 32A
Output power – 7KW
Insulation resistance – 1000V DC，≥10M
Withstand voltage – 2500V AC（Input/output to ground）

Configuration : floor-standing
Other characteristics : single-phase
Applications : for electric vehicles
Amperage : 32 A
Nominal voltage : 220 V
