Electro-hydraulic tilterBN series

Tilt angle up to 90°

The container tilter is designed for heavy containers and skeleton containers. With a tilt angle of up to 90° it allows for easy unloading of a container without the operator having to bend
over. Depending on individual requirements it can be supplied with
1. electro-hydraulic pump or
2. foot pump.

Standard fittings
I Load-bearing capacity of 1000 or 1500 kg
I Tilt angle 90° max.
I Operating voltage 12V, 230V, 400V
I Wheels with Ø 200/85 mm
I Dimensions: length 1230 mm, with 740 mm, fork length 820 mm, fork width 550 mm
Tilt angle up to 90 °
8 I
Container tilter with foot pump
Container tilter BN-SH

BN-SH
The container tilter BN-SH is the stationary version of the BN. It tilts to an angle of up to 90°. Instead of featuring load-bearing forks it is equipped to receive 900 x 1250 mm skeleton
boxes. Fork lift trucks are used for loading.

Standard fittings
I Load-bearing capacity of 1000 or 2000 kg
I Tilt angle 90° max.
I Operating voltage 400 V
I Control voltage 230 V
I Side casing as safety feature

Operation : electro-hydraulic
Applications : case
Other characteristics : 90°, mobile
