External dimensions:
900 x 1320 x 1750 mm

Weight:
ca. 230 kg

Power supply:
3 Phase, 230/400 V, 50 Hz
(Special voltages on request)

Working height / belt height:
865 – 995 mm (vom Boden gemessen)

Water tank:
ca. 170 Liter

Heating system:
Steam-/ Electric heater

FEATURES
• High-performance electric motor
• Water level monitoring
• Dip-chamber cover
• Dip function 250 mm
• High-performance heating element

FEATURE EQUIPMENT ATT 77/6
CONTROL SYSTEM DIP 1500
• Program memory function
• Dip time, conveyor time and temperature freely adjustable
• Self-cleaning function
• Pass-through function for non-shrink bags
• Time of day adjustable
• Timed preheat function

ACCESSORIES
• Steam heating version (for connection to the domestic steam system)
• Additional heating system (power: 9,5 KW)
• Outside connecting rolling track made of stainless steel (10 rollers, height-adjustable) (e.g. as a connection to the packaging machine)
• Outside connecting rolling track made of stainless steel (5 rollers, height-adjustable) (e.g. as a connection to the dryer T 1100 A)

Type : electric
Specifications : steam
