● The machine adopts flat-bed mode and the material runs stably.
● Servo motor controls the driving to ensure precise material transportation.
● The machine has auto edge correction and electric eye tracer which ensure high precise die-cutting.
● It can do die-cutting, waste-off, sheeting and rewinding in one process.
● It is optional for the machine to add separate unwinding unit, lamination, stamping and punching.
● Multi-function design makes the machine fit for adhesive, Nylon, laser anti-counterfeit and blank label die-cut. It is a complementary equipment for rotary label printing machine, flexo printer, screen printer etc.
Max. Unwinding Dia: 600mm
Max. Paper Width: 350mm
Die-cutting Precision: ±0.1mm
Main Power: 5.5kw
Supply Voltage: 220V±10%
Technology : die
Material : for paper
Product handled : label
Associated function : multi-function
Other characteristics : high-precision, rotary
X travel : 340 mm (13 in)
Y travel : 340 mm (13 in)
Overall width : 1,280 mm (50 in)
Overall length : 4,425 mm (174 in)
Height : 1,840 mm (72 in)
Weight : 4,000 kg (8,818 lb)
